Hybrid Inverter
4Kw Hybird Inverter
Discover the 4Kw Hybird Inverter, a high - performance device that combines the best of both worlds. It efficiently converts DC to AC power, suitable for various applications. It supports both grid - connected and off - grid operations, offering great flexibility. With advanced technology, it ensures stable power output, high conversion efficiency, and reliable protection functions. Ideal for home solar power systems and small - scale commercial setups, this inverter provides a cost - effective and sustainable power solution.
Discover the 4Kw Hybird Inverter, a high - performance device that combines the best of both worlds. It efficiently converts DC to AC power, suitable for various applications. It supports both grid - connected and off - grid operations, offering great flexibility. With advanced technology, it ensures stable power output, high conversion efficiency, and reliable protection functions. Ideal for home solar power systems and small - scale commercial setups, this inverter provides a cost - effective and sustainable power solution.
| MODEL | VMS-V-4.2K-24-H |
| Rated Power | 4200W |
| ACInput/Output | |
| Voltage | 220/230/240VAC |
| Outpu Waveform | Pure sine wave |
| Frequency Range | 50 Hz/60 Hz |
| Grid-tie Output: | |
| Feed-n Grid voltage Range | 195~253VAC |
| Feed-in Grid Frequency Range | 49-51±1HZ/59-61±1HZ |
| Maximum Load | 4200W |
| Maximum Second Load | 1400W |
| Battery&AC Charger | |
| Battery Voltage | 20-33VDC |
| Floating Charge voltage | 27VDC |
| Overcharge Protection | 33VDC |
| Solar charger &AC charger | |
| Solar Charger Type | MPPT |
| MaximumPVArray Power | 6200W |
| MaxSolar Charging Curent | 120A |
| MPPT Range@OperatingVoltage | 120~450VDC |
| Maximum Solar Charge Current | 120A |
| MaxACCharging Current | 100A |
| Nominal PVVoltage | 240VDC |
| Maximum PVArray Open Circuit Voltage | 500 VDC |
| BMS Communication Interface | RS485 |
| APP Monitoring Interface | RS232 |
| Physical | |
| Dimension,DWH(mm) | 120×344×440mm |
| NetWeight (kgs) | 8.5kg |
| Operating Environment | |
| Humidity | 5%to 95%Relative Humidity(Non-condensing) |
| Operating Temperature | -10℃-50℃ |
| Storage Temperature | -15℃-60℃ |
